Database Schema Goals

  1. Referential integrity in data source
    • Add an RDBMS - MySQL likely - that uses a schema designed to store the data required for business rules and update metadata -- including data points we may not even track currently (these need to be defined).
  2. No duplication of data
    • Basic normalization (without OVER normalizing) should quite easily take care of this.

Proposed Solution

Using this less than completely normalized solution is theorized to be faster. Rather than using joins, each table will have it's value looked up with an independent query. Caching the results of these queries will minimize actual hits on the database.

Collapsed



Mapping Files To Tables

In mapping the pathname to database fields, each segment in the path leads to an entry in a database table:

incoming/2/Firefox/trunk/Linux_x86-gcc3/2007061204/en-US/complete.txt -> Product.name

incoming/2/Firefox/trunk/Linux_x86-gcc3/2007061204/en-US/complete.txt -> Version.name

incoming/2/Firefox/trunk/Linux_x86-gcc3/2007061204/en-US/complete.txt -> Build_target.name

incoming/2/Firefox/trunk/Linux_x86-gcc3/2007061204/en-US/complete.txt -> Build.name

incoming/2/Firefox/trunk/Linux_x86-gcc3/2007061204/en-US/complete.txt -> locale.name

However, that leaves four tables with no source of values:

? -> channel.name


? -> os_version.name


? -> Distribution.name


? -> Distibution_version.name

The rest of the values to be mapped into the database come from the complete.txt and partial.txt files. An example mapping follows:

complete  -> patches.type
http://ftp.mozilla.org/pub/mozilla.org/firefox/nightly/2007-06-12-07-trunk/firefox-3.0a6pre.en-US.linux-i686.complete.mar -> patches.URL
sha1 -> patches.hashFunction
4fe7d4db03ef96eb8f34bce05d740d986fcb0bc0 -> patches.hashValue
10752925 -> ??
2007061207 -> ??
3.0a6pre -> updates.version
3.0a6pre -> updates.extensionVersion

Unfortunately, that leaves three columns in two tables without a data source:

?? -> updates.types

?? -> updates.detailsURL

?? -> patches.size

table 1: updates

column name type attribute comment
id sequence primary
type varchar | enum | integer   several options for implementation
version varchar   likely a foreign key?
extensionVersion varchar   likely a foreign key?
detailsURL varchar   is this url completely unique?


id type version extensionVersion detailsURL
0 minor 1.0.4 1.0 http://www.foo.com/1.0.4/whatsnew.html
1 major 1.1.2 1.1 http://www.foo.com/1.1.2/whatsnew.html

table 2: patches

column name type attribute comment
id sequence primary
type varchar | enum | integer   several options for implementation
URL varchar   is this url completely unique?
hashFunction varchar
hashValue varchar
size varchar   if it's never actually
used as an integer
updateId integer FK(updates)


id type URL hashFunction hashValue size updateId
0 partial http://www.foo.com/1.0.4-partial.mar       0
1 complete http://www.foo.com/1.0.4-complete.mar       0
2 complete http://www.foo.com/1.1.2-complete.mar       1

table 3: UpdateParameters

column name type attribute comment
id sequence primary
productId integer FK(product)
versionId integer FK(version)
build_idId integer FK(build_id)
build_targetId integer FK(build_target)
localeId integer FK(locale)
channelId integer FK(channel)
os_versionId integer FK(os_version)
distributionId integer FK(distribution)
distribution_versionId integer FK(distribution_version)
updateId integer FK(updates)

table 4: Product

column name type attribute comment
id sequence primary
name varchar

table 5: Version

column name type attribute comment
id sequence primary
name varchar

table 6: buildId

column name type attribute comment
id sequence primary
name varchar

table 7: buildTarget

column name type attribute comment
id sequence primary
name varchar

table 8: Locale

column name type attribute comment
id sequence primary
name varchar

table 9: Channel

column name type attribute comment
id sequence primary
name varchar

table 10: Os_version

column name type attribute comment
id sequence primary
name varchar

table 11: Distribution

column name type attribute comment
id sequence primary
name varchar

table 11: Distribution_version

column name type attribute comment
id sequence primary
name varchar

Previous Proposals

Fully Normalized Hierarchy


Stats:

  • number of tables: 17
  • number of joins to get data: 16

Sample SQL:

select
  payload.*
from
  product join pv on (product.name = %PRODUCT% and product.id = pv.productId)
            join version on (version.name = %VERSION% and version.id = pv.versionId)
              join pvb on (pv.id = pvb.pvId)
                join build_id on (build_id.name = %BUILD_ID% and build_id.id = pvb.build_idId)
                  join pvbbt on (pvb.id = pvbbt.pvbId)
                    join build_target on (build_target.name = %BUILD_TARGET% and build_target.id = pvbbt.build_targetId)
                      join pvbbtl on (pvbbt.id = pcbbtl.pvbbtId)
                        join locale on (locale.name = %LOCALE% and locale.id = pvbbtl.localId)
                          join pvbbtlc on (pvbbtl.id = pvbbtlc.pvbbtlId)
                            join channel on (channel.name = %CHANNEL% and channel.id = pvbbtlc.channelId)
                              join pvbbtlcos on (pvbbtlc.id = pcvbbtlcos.pvbbtlcId)
                                join os_version on (os_version.name = %OS_VERSION% and os_version.id = pvbbtlcos.os_versionId)
                                  join pvbbtlcosd on (pvbbtlcos.id = pvbbtlcosd.pcbbtlcosId)
                                    join distribution in (distribution.name = %DISTRIBUTION% and distribution.id = pvbbtlcosd.distributionId)
                                      join payload on (pvbbtlcosd.id = payload.pvbbtlcosdId)
                                        join distibution_version on (distibution_version.name = %DISTRIBUTION_VERSION% and distibution_version.id = payload.distibution_versionId)

Advantages:

  • simulates the original hierarchical structure
  • highly normalized

Disadvantages:

  • very verbose SQL
  • structure, while faithful to the previous system, doesn't necessarily accurately model the data relationships

Mostly Normalized Hierarchy with Rearrangement


Stats

  • number of tables: 16
  • number of joins: 15

Sample SQL

select
  payload.*
from
  payload join (product join pv on (product.name = %PRODUCT% and product.id = pv.productId)
                          join version on (version.name = %VERSION% and version.id = pv.versionId)
                            join pvb on (pv.id = pvb.pvId)
                              join build_id on (build_id.name = %BUILD_ID% and build_id.id = pvb.build_idId))
                on payload.pvbId = pcbId.id
            join (btos join build_target on (build_target.name = %BUILD_TARGET% and build_target.id = btos.build_targetId)
                         join os_version on (os_version.name = %OS_VERSION% and os_version.id = btos.os_versionId)
                           join btosl on (btos.id = btosl.btosId)
                             join locale on (locale.name = %LOCALE% and locale.id = btosl.localeId))
                  on payload.btoslId = btosl.id
               join (cd join channel on (channel.name = %CHANNEL% and channel.id = cd.channelId)
                          join distribution on (distribution.name = %DISTRIBUTION% and distribution.id = cd.distributionId)
                            join cddv on (cd.id = cddv.cdId)
                              join distribution_version on (distribution_version.name = %DISTRIBUTION_VERSION% and distribution_version.id = cddv.distribution_versionId))
                     on payload.cddvId = cddv.id

Advantages

  • normalized
  • rearrangement more accurately reflect the data relationships

Disadvantages

  • complicated SQL

Collapsed



Stats:

  • number of tables: 10
  • number of joins to get data: 9

Sample SQL:

select
  payload.*
from
  payload join product on (product.name = %PRODUCT% and product.id = payload.productId)
            join version on (version.name = %VERSION% and version.id = payload.versionId)
              join build_id on (build_id.name = %BUILD_ID% and build_id.id = payload.build_idId)
                join build_target on (build_target.name = %BUILD_TARGET% and build_target.id = payload.build_targetId)
                  join locale on (locale.name = %LOCALE% and locale.id = payload.localId)
                    join channel on (channel.name = %CHANNEL% and channel.id = payload.channelId)
                      join os_version on (os_version.name = %OS_VERSION% and os_version.id = payload.os_versionId)
                        join distribution in (distribution.name = %DISTRIBUTION% and distribution.id = payload.distributionId)
                          join distibution_version on (distibution_version.name = %DISTRIBUTION_VERSION% and distibution_version.id = payload.distibution_versionId)


Advantages

  • fewer joins means faster queries

Disadvantages

  • poor normalization
  • no direct expression of the relationships between the keys

Degenerate

No Image

The information is stored in a single table keyed by the entire URL.

Stats:

  • number of tables: 1
  • number of joins to get data: 0

Sample SQL:

select payload.* from payload where url = %URL%


Advantages

  • fastest of the options
  • no complicated SQL to maintain

Disadvantages

  • no relationships between keys stored in the database

Metadata First Cut

Converting an XML Schema into a relational database schema can be pretty straight forward. An element generally corresponds with a row in a table. The attributes inside the start tags correspond to the data in columns of the table. Nested elements are rows in another table that has a foreign key relationship with the table to which the parent element is associated. The tree structure of XML lends itself to orderly relational database schema.

While more complicated relationships can exist between the elements, the schema of this project seems very simple.

<?xml version="1.0"?>

<updates>
  <update type="minor" version="1.0.4" extensionVersion="1.0"
          detailsURL="http://www.foo.com/1.0.4/whatsnew.html">
    <patch type="partial" URL="http://www.foo.com/1.0.4-partial.mar"
           hashFunction="" hashValue="" size=""/>
    <patch type="complete" URL="http://www.foo.com/1.0.4-complete.mar"
           hashFunction="" hashValue="" size=""/>
  </update>
  ..
  <update type="major" version="1.1.2" extensionVersion="1.1"
          detailsURL="http://www.foo.com/1.1.2/whatsnew.html">
    <patch type="complete" URL="http://www.foo.com/1.1.2-complete.mar"
           hashFunction="" hashValue="" size=""/>
  </update>
</updates>

AUS Metadata Database Schema Naive Version 1

This proposal introduces just two tables: updates and patches. They correspond to the major elements of the aforementioned XML file.

table 1: updates

column name type attribute comment
id sequence primary
type varchar | enum | integer   several options for implementation
version varchar   likely a foreign key?
extensionVersion varchar   likely a foreign key?
detailsURL varchar   is this url completely unique?


id type version extensionVersion detailsURL
0 minor 1.0.4 1.0 http://www.foo.com/1.0.4/whatsnew.html
1 major 1.1.2 1.1 http://www.foo.com/1.1.2/whatsnew.html

table 2: patches

column name type attribute comment
id sequence primary
type varchar | enum | integer   several options for implementation
URL varchar   is this url completely unique?
hashFunction varchar
hashValue varchar
size varchar   if it's never actually
used as an integer
updateId integer FK(updates)


id type URL hashFunction hashValue size updateId
0 partial http://www.foo.com/1.0.4-partial.mar       0
1 complete http://www.foo.com/1.0.4-complete.mar       0
2 complete http://www.foo.com/1.1.2-complete.mar       1

Discussion

This schema is missing any indication of the product. Does this system need to take into account more than just one product? If is does, imagine another enclosing

How does this schema meet the goals at the top of the page?

  1. ...data required for business rules and update metadata...: What are the business rules? Can't test to see if this is sufficient for the business rules until I have business rules. If the "update metadata" is captured in its entirety by the XML example, the it is safe to judge that this database schema is equivalent.
  2. Basic normalization (without OVER normalizing)...: This simple schema is normalized if the values in the columns are unique. Each table has a type attribute that could be foreign keys to tables listing the allowed types. Since there are so few options, splitting them off into their own tables would be over normalization. The URL columns, if not unique within their tables, could be consolidated into their own tables leaving behind a foreign key.
